Adet bazlı fiyat
- 1+ adet$4.21
- 10+ adet$3.97
- 100+ adet$3.75
- 500+ adet$3.54
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Montaj
- Surface Mount
- Coil Power
- 250mW
- Operate Time
- 4ms
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -40°C~85°C
- Throw Configuration
- DPDT
- Must Release Voltage
- 0.15VDC
- Body Breadth
- 7.4 mm
- Switching Voltage
- 110VDC -Max
- Power Consumption
- 250mW
- Terminal Stili
- Gull Wing
- Coil Type
- Non Latching
- Kontak Formu
- DPDT (2 Form D)
- Nem Hassasiyeti (MSL)
- 4 (72 Hours)
- Seal Rating
- Sealed - Fully
- Release Time
- 4 ms
- Contact Materials
- Silver (Ag), Gold (Au)
- Max Voltage Rating Dc
- 110V
- Insertion Loss Db
- 0.8 dB
- Body Length Or Diameter
- 15mm
- Additional Feature
- LOW PROFILE
- Coil Voltage Dc
- 1.5V
- Relay Type
- General Purpose
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 18 Weeks
- Relay Action
- MOMENTARY
- Kurşunsuz
- Lead Free
- RoHS Durumu
- RoHS Compliant
- Ambalaj
- Tube
- Sealing
- WATER PROOF
- Terminal
- Gull Wing
- Contact Dc Max Rating R Load
- 1A@110VDC
- Coilresistance
- 9Ohm
- Coil Voltage
- 1.5VDC
- Coilinput Supply Type
- DC
- Must Operate Voltage
- 1.13VDC
- Coil Current
- 167mA
- Contact Currentdcmax
- 1A
- Reference Standard
- BSI; CSA; EN; UL
