Adet bazlı fiyat
- 1+ adet$3.04
- 10+ adet$2.87
- 100+ adet$2.70
- 500+ adet$2.55
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Depth
- 7.4mm
- Contact Dc Max Rating R Load
- 2A@220VDC
- Terminal
- PC Pin
- Kılıf / Paket
- DIP
- Must Operate Voltage
- 2.25VDC
- Coilinput Supply Type
- DC
- Coil Voltage
- 3VDC
- Coilresistance
- 45Ohm
- Max Current Rating
- 2A
- Reference Standard
- BSI; CSA; EN; UL
- Coil Current
- 66.7mA
- Contact Currentdcmax
- 2A
- Contactoutput Supply Type
- DC
- Montaj Tipi
- Through Hole
- Seri
- TX-D
- Electricallife
- 100000 Cycle(s)
- Pin Sayısı
- 8
- Weight
- 2g
- Must Release Voltage
- 0.3VDC
- Throw Configuration
- DPDT
- Çalışma Sıcaklığı
- -40°C~85°C
- Parça Durumu
- Active
- Operate Time
- 4ms
- Coil Power
- 200mW
- Montaj
- Through Hole
- Release Time
- 4 ms
- Seal Rating
- Sealed - Fully
- Coil Type
- Non Latching
- Kontak Formu
- DPDT (2 Form C)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Stili
- PC Pin
- Uzunluk
- 15mm
- Switching Voltage
- 220VDC -Max
- Power Consumption
- 200mW
- Max Voltage Rating Dc
- 220V
- Insertion Loss Db
- 0.8 dB
- Contact Materials
- Silver (Ag), Gold (Au)
- Sealing
- WATER PROOF
- Ambalaj
- Tube
- RoHS Durumu
- RoHS Compliant
