Teknik Özellikler
- Coilinput Supply Type
- DC
- Yayın Yılı
- 2004
- Kılıf / Paket
- DIP
- Operate Time
- 3ms
- Contact Currentdcmax
- 0.1A
- Empedans
- 50Ohm
- Coil Type
- Non Latching
- Max Current Rating
- 100mA
- Insulation Resistance
- 1000000000Ohm
- Relay Type
- RF
- Pcb Hole Count
- 6
- Coilresistance
- 1.03kOhm
- Release Time
- 2ms
- Relay Action
- LATCHED
- Electricallife
- 100000 Cycle(s)
- Pin Sayısı
- 6
- Contact Resistance
- 50mOhm
- Contactoutput Supply Type
- DC
- Montaj Tipi
- Through Hole
- Depth
- 9mm
- Must Release Voltage
- 1.2VDC
- Frekans
- 1.8GHz
- Dielectric Strength Between Open Contacts
- 750 Vrms
- Coil Voltage
- 12VDC
- Must Operate Voltage
- 9VDC
- Seri
- RP
- Çalışma Sıcaklığı
- -40°C~70°C
- Coil Current
- 11.7mA
- Throw Configuration
- SPDT
- Contact Materials
- Silver (Ag), Gold (Au)
- ECCN Kodu
- EAR99
- Insertion Loss Db
- 0.5 dB
- Coil Voltage Dc
- 12V
- Kurşunsuz
- Lead Free
- Parça Durumu
- Obsolete
- Contact Dc Max Rating R Load
- 0.1A@30VDC
- Terminal
- PC Pin
- Terminal Sayısı
- 6
- Montaj
- PCB, Through Hole
- Yükseklik
- 3.75mm
