Teknik Özellikler
- Çalışma Sıcaklığı
- -40°C~70°C
- Switching Time
- 16 ms
- Throw Configuration
- SPDT
- Kontak Formu
- SPDT (1 Form C)
- Weight
- 4.4g
- Body Height
- 9.7mm
- Parça Durumu
- Obsolete
- Physical Dimension
- 20.2mm x 11.2mm x 9.7mm
- RoHS Durumu
- RoHS Compliant
- Ambalaj
- Tube
- Montaj Tipi
- Through Hole
- Yayın Yılı
- 2004
- Contactoutput Supply Type
- DC
- Relay Type
- RF
- ECCN Kodu
- EAR99
- Release Time
- 6ms
- JESD-609 Kodu
- e4
- Max Voltage Rating Dc
- 30V
- Operate Time
- 10ms
- Coil Voltage Dc
- 12V
- Relay Action
- LATCHED
- HTS Kodu
- 8536.41.00.20
- Vswr
- 1.5
- Switching Voltage
- 30VDC -Max
- Additional Feature
- HIGH FREQUENCY CHARACTERISTICS FOR 75 OHMS ALSO AVAILABLE, VSWR AND INSERTION LOSS TAKEN AT 900 MHZ
- Max Current Rating
- 500mA
- Contact Dc Max Rating R Load
- .5A@30VDC
- Coilresistance
- 360Ohm
- Switching Current
- 500mA
- Terminal Stili
- PC Pin
- Empedans
- 75Ohm
- Power Consumption
- 400mW
- Coil Voltage
- 12VDC
- Electricallife
- 300000 Cycle(s)
- Coil Type
- Latching, Dual Coil
- Ratings
- IP67
- Isolationmax
- 60 dB
- Packing Method
- BULK
- Contact Materials
- Gold
- Insertion Loss Db
- 0.3 dB
