Teknik Özellikler
- Insertion Loss Db
- 0.3 dB
- Contact Materials
- Gold
- Must Release Voltage
- 2.4VDC
- Packing Method
- BULK
- Parça Durumu
- Obsolete
- Isolationmax
- 60 dB
- Rise Time
- 6ms
- Input Powermax Cw
- 10W
- Electricallife
- 300000 Cycle(s)
- Coil Type
- Non Latching
- Coil Voltage
- 24VDC
- Power Consumption
- 200mW
- Kontak Formu
- SPDT (1 Form C)
- Empedans
- 75Ohm
- Throw Configuration
- SPDT
- Terminal Stili
- PC Pin
- Uzunluk
- 20.2mm
- Depth
- 11.2mm
- Çalışma Sıcaklığı
- -40°C~70°C
- Kurşunsuz
- Lead Free
- Coilresistance
- 2.88kOhm
- Contact Dc Max Rating R Load
- .5A@30VDC
- Max Current Rating
- 500mA
- Özellikler
- Sealed - Fully
- Switching Voltage
- 30VDC -Max
- Coil Current
- 8.3mA
- Montaj
- Through Hole
- Vswr
- 1.5
- Terminal
- PC Pin
- Seri
- RK
- HTS Kodu
- 8536.41.00.20
- Relay Action
- MOMENTARY
- Coil Voltage Dc
- 24V
- Operate Time
- 10ms
- Max Voltage Rating Dc
- 30V
- JESD-609 Kodu
- e4
- Pin Sayısı
- 9
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Relay Type
- RF
- Coilinput Supply Type
- DC
