Adet bazlı fiyat
- 1+ adet$0.57
- 10+ adet$0.54
- 100+ adet$0.51
- 500+ adet$0.48
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Terminal
- PC Pin
- Power Consumption
- 250mW
- Seri
- LK-T
- Coil Type
- Non Latching
- Max Current Rating
- 8A
- Relay Type
- General Purpose
- Kurşunsuz Kodu
- yes
- Voltage Rated Ac
- 277V
- Coil Voltage Dc
- 12V
- Coilresistance
- 576Ohm
- RoHS Durumu
- RoHS Compliant
- Coil Current
- 20.8mA
- Operate Time
- 15ms
- Uzunluk
- 24mm
- Must Release Voltage
- 1.2VDC
- Pin Sayısı
- 4
- Kontak Formu
- SPST-NO (1 Form A)
- Seal Rating
- Sealed - Flux Protection
- Number Of Elements
- 1
- Depth
- 11mm
- Kurşunsuz
- Lead Free
- Max Voltage Rating Ac
- 277V
- Contact Rating Current
- 5A
- Parça Durumu
- Active
- Ambalaj
- Tube
- Must Operate Voltage
- 8.4VDC
- Additional Feature
- HIGH SENSITIVITY, UL APPROVED, VDE APPROVED
- Release Time
- 5ms
- Coil Voltage
- 12VDC
- Fabrika Tedarik Süresi
- 14 Weeks
- Coil Power
- 250mW
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yayın Yılı
- 2005
- Montaj Tipi
- Through Hole
- Weight
- 12g
- Optoelectronic Device Type
- TRANSISTOR OUTPUT SSR
- Montaj
- Through Hole
- Switching Voltage
- 277VAC -Max
- Onstate Currentmax
- 8A
- Çalışma Sıcaklığı
- -40°C~70°C
