Adet bazlı fiyat
- 1+ adet$12.51
- 10+ adet$11.81
- 100+ adet$11.14
- 500+ adet$10.51
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Materials
- Silver Tin Oxide (AgSnO)
- Throw Configuration
- SPST
- Terminal Stili
- PC Pin
- Çalışma Sıcaklığı
- -40°C~70°C
- Switching Voltage
- 277VAC -Max
- Optoelectronic Device Type
- TRANSISTOR OUTPUT SSR
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yayın Yılı
- 2003
- Montaj Tipi
- Through Hole
- Ratings
- IP54
- Fabrika Tedarik Süresi
- 12 Weeks
- Coil Voltage
- 24VDC
- Additional Feature
- HIGH SENSITIVITY, UL APPROVED
- Release Time
- 20ms
- Must Operate Voltage
- 18VDC
- Ambalaj
- Box
- Parça Durumu
- Active
- Switching Current
- 16A
- Seal Rating
- Sealed - Flux Protection
- Depth
- 11mm
- Number Of Elements
- 1
- Pin Sayısı
- 4
- Kontak Formu
- SPST-NO (1 Form A)
- Must Release Voltage
- 2.4VDC
- Uzunluk
- 24mm
- Operate Time
- 15ms
- RoHS Durumu
- RoHS Compliant
- Coil Current
- 22.1mA
- Coilresistance
- 1.09kOhm
- Kurşunsuz Kodu
- yes
- Coil Voltage Dc
- 24V
- Voltage Rated Ac
- 277V
- Relay Type
- General Purpose
- Terminal
- PC Pin
- Seri
- LK-G
- Coil Type
- Non Latching
