Adet bazlı fiyat
- 1+ adet$2.60
- 10+ adet$2.45
- 100+ adet$2.31
- 500+ adet$2.18
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Terminal
- PC Pin
- Power Consumption
- 530mW
- Seri
- LK-G
- Coil Type
- Non Latching
- Max Current Rating
- 16A
- Coilresistance
- 272Ohm
- Relay Type
- General Purpose
- Kurşunsuz Kodu
- yes
- Coil Voltage Dc
- 12V
- Voltage Rated Ac
- 277V
- RoHS Durumu
- RoHS Compliant
- Coil Current
- 44.2mA
- Must Release Voltage
- 1.2VDC
- Pin Sayısı
- 4
- Kontak Formu
- SPST-NO (1 Form A)
- Operate Time
- 15ms
- Uzunluk
- 24mm
- Max Voltage Rating Ac
- 277V
- Ambalaj
- Bulk
- Parça Durumu
- Active
- Must Operate Voltage
- 9VDC
- Seal Rating
- Sealed - Flux Protection
- Depth
- 11mm
- Number Of Elements
- 1
- Kurşunsuz
- Lead Free
- Switching Current
- 16A
- Coil Voltage
- 12VDC
- Fabrika Tedarik Süresi
- 12 Weeks
- Additional Feature
- HIGH SENSITIVITY, UL APPROVED
- Release Time
- 20ms
- Weight
- 12g
- Optoelectronic Device Type
- TRANSISTOR OUTPUT SSR
- Ratings
- IP54
- Coil Power
- 530mW
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yayın Yılı
- 2003
- Montaj Tipi
- Through Hole
- Çalışma Sıcaklığı
- -40°C~70°C
- Throw Configuration
- SPST
- Contact Materials
- Silver Tin Oxide (AgSnO)
