Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Coil Voltage
- 4.5VDC
- Switching Time
- 20 ms
- Throw Configuration
- SPDT
- Contactoutput Supply Type
- DC
- Parça Durumu
- Obsolete
- Characteristic Impedance
- 50Ohm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Dielectric Strength Between Coil And Contacts
- 1000 Vrms
- Input Powermax Cw
- 20W
- Montaj
- Through Hole
- Dielectric Strength Between Open Contacts
- 500 Vrms
- Depth
- 12.4mm
- Relay Action
- MOMENTARY
- Coil Voltage Dc
- 4.5V
- Weight
- 5g
- Switching Voltage
- 30VDC -Max
- Terminal
- PC Pin
- Yayın Yılı
- 2004
- Ambalaj
- Tube
- Contact Resistance
- 100mOhm
- Operate Time
- 10ms
- Seri
- ARX
- Release Time
- 6ms
- Coilinput Supply Type
- DC
- Contact Currentdcmax
- 0.5A
- Pcb Hole Count
- 9
- Must Operate Voltage
- 3.38VDC
- Uzunluk
- 20.5mm
- Pin Sayısı
- 6
- Kontak Formu
- SPDT (1 Form C)
- Coil Type
- Non Latching
- Insertion Loss Db
- 0.2 dB
- Voltage Rated Dc
- 30V
- Power Consumption
- 200mW
- Radyasyon Dayanımı
- No
- Electricallife
- 100000 Cycle(s)
- Contact Dc Max Rating R Load
- .5A@30VDC
- Max Current Rating
- 500mA
- Packing Method
- BOX
- Contact Materials
- Gold Plating
