Adet bazlı fiyat
- 1+ adet$13.11
- 10+ adet$12.36
- 100+ adet$11.66
- 500+ adet$11.00
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Operate Time
- 10ms
- Must Operate Voltage
- 2.25VDC
- Coil Current
- 66.7mA
- Contact Currentdcmax
- 0.5A
- Input Switching Control Type
- Random
- Isolationmax
- 30 dB
- Terminal Kaplaması
- Gold (Au)
- Seri
- ARS
- Switching Voltage
- 30VDC -Max
- HTS Kodu
- 8536.41.00.20
- Yayın Yılı
- 2004
- Vswr
- 1.5
- Weight
- 2g
- Coil Voltage Dc
- 3V
- Parça Durumu
- Active
- Packing Method
- TAPE AND REEL
- ECCN Kodu
- EAR99
- Relay Action
- MOMENTARY
- Relay Type
- RF RELAY
- Body Breadth
- 8.6 mm
- Ambalaj
- Tape & Reel (TR)
- RoHS Durumu
- RoHS Compliant
- JESD-609 Kodu
- e4
- Contact Materials
- Gold Plating
- Operating Frequency Max
- 3000MHz
- Montaj
- Surface Mount
- Terminal Stili
- Gull Wing
- Electricallife
- 300000 Cycle(s)
- Coil Power
- 200mW
- Nem Hassasiyeti (MSL)
- 4 (72 Hours)
- Input Powermax Cw
- 1W
- Coil Type
- Non Latching
- Switching Time
- 16 ms
- Contact Resistance
- 100mOhm
- Empedans
- 75Ohm
- Max Voltage Rating Dc
- 30V
- Coil Voltage
- 3VDC
- Dielectric Strength Between Coil And Contacts
- 1000 Vrms
- Max Current Rating
- 500mA
- Contact Dc Max Rating R Load
- .5A@30VDC
