FAN25800AUCF27X

Teknik Özellikler

Kılıf / Paket

4-XFBGA, WLCSP

Dropout Voltage1nom

0.07V

Genişlik

650μm

Tepe Reflow Sıcaklığı (°C)

260

Ambalaj

Tape & Reel (TR)

Montaj Tipi

Surface Mount

Output Voltage1

2.7V

Montaj

Surface Mount

Protection Features

Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)

Min Input Voltage

2.3V

Output Voltage

2.7V

Voltage Input Max

5.5V

Control Features

Enable

Lifecycle Status

LAST SHIPMENTS (Last Updated: 1 week ago)

Kurşunsuz Kodu

yes

Weight

42mg

Qualification Status

Not Qualified

Parça Durumu

Obsolete

Output Configuration

Positive

Operating Supply Current

17μA

Çıkış Tipi

Fixed

Terminal Sayısı

4

RoHS Durumu

ROHS3 Compliant

Voltage Dropout Max

0.13V @ 250mA

Çalışma Sıcaklığı

-40°C~85°C

Number Of Outputs

1

Nem Hassasiyeti (MSL)

1 (Unlimited)

Current Quiescent Iq

25μA

ECCN Kodu

EAR99

Yayın Yılı

2016

Tepe Reflow Süresi (maks. sn)

NOT SPECIFIED

Input Voltage Absolutemax

6V

Max Output Current

500mA

JESD-609 Kodu

e1

Uzunluk

650μm

Dropout Voltage

70mV

Min Current Limit

550mA

Input Bias Current

1μA

Usage Level

Industrial grade

Accuracy

1.9 %
