Teknik Özellikler
- Pozisyon Sayısı
- 9
- Contact Finish
- Gold
- Shell Material Finish
- Steel, Nickel Plated
- Reference Standard
- UL
- Number Of Pcb Rows
- 2
- Terminal
- Solder
- Insulation Resistance
- 1000000000Ohm
- Flange Feature
- Mating Side, Female Screwlock (4-40)
- Contact Finish Thickness
- Flash
- Shell Size Connector Layout
- 1 DE E
- Orientation
- Right Angle
- Connector Type
- Plug, Male Pins
- Montaj
- Panel, Through Hole
- Material Flammability Rating
- UL94 V-0
- Montaj Tipi
- Panel Mount, Through Hole, Right Angle
- Fabrika Tedarik Süresi
- 7 Weeks
- Total Number Of Contacts
- 9
- Akım Değeri
- 3A
- JESD-609 Kodu
- e4
- Renk
- Black
- Contact Materials
- Brass
- Pitch
- 2.77mm
- Özellikler
- Board Lock, Shielded
- RoHS Durumu
- RoHS Compliant
- Dielectric Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Rated Current Signal
- 3A
- Housing Material
- PBT
- Sıra Sayısı
- 2
- Contact Type
- Signal
- Nominal Gerilim
- 300V
- Çalışma Sıcaklığı
- -25°C~105°C
- Seri
- XM3C
- Parça Durumu
- Active
- Connector Style
- D-Sub
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Dielectric Withstanding Voltage
- 1000VAC V
- Yayın Yılı
- 2013
- Pcb Contact Pattern
- STAGGERED
- Reliability
- COMMERCIAL
