Adet bazlı fiyat
- 1+ adet$6.02
- 10+ adet$5.68
- 100+ adet$5.36
- 500+ adet$5.05
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Parça Durumu
- Active
- Seri
- XM3B
- Nominal Gerilim
- 300V
- Çalışma Sıcaklığı
- -55°C~105°C
- Yayın Yılı
- 2001
- Din Conformance
- NO
- Ambalaj
- Tray
- Connector Style
- D-Sub
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Özellikler
- Board Lock, Shielded
- Pitch
- 2.74mm
- Contact Materials
- Phosphor Bronze
- Renk
- Black
- Empty Shell
- NO
- JESD-609 Kodu
- e3
- Akım Değeri
- 5A
- Contact Type
- Signal
- Housing Material
- PBT
- Sıra Sayısı
- 2
- Dielectric Material
- Polybutylene Terephthalate (PBT), Glass Filled
- RoHS Durumu
- RoHS Compliant
- Connector Type
- Receptacle, Female Sockets
- HTS Kodu
- 8536.69.40.30
- Shell Size Connector Layout
- 2 DA A
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Orientation
- Right Angle
- Contact Finish Thickness
- 16.0μin 0.41μm
- Additional Feature
- EMI SHIELDED
- Flange Feature
- Mating Side, Female Screwlock (4-40)
- Mil Conformance
- NO
- Total Number Of Contacts
- 15
- Fabrika Tedarik Süresi
- 12 Weeks
- Iec Conformance
- NO
- Montaj Tipi
- Panel Mount, Through Hole, Right Angle
- Material Flammability Rating
- UL94 V-0
- Kurşunsuz Kodu
- yes
- Montaj
- Through Hole
- Shell Material Finish
- Steel, Nickel Plated
- Option
- GENERAL PURPOSE
- Contact Finish
- Gold
