Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Terminal
- Solder
- Number Of Pcb Rows
- 2
- Reference Standard
- UL
- Shell Material Finish
- Steel, Nickel Plated
- Pozisyon Sayısı
- 9
- Contact Finish
- Gold
- Fabrika Tedarik Süresi
- 10 Weeks
- Total Number Of Contacts
- 9
- Material Flammability Rating
- UL94 V-0
- Montaj
- Through Hole
- Montaj Tipi
- Panel Mount, Through Hole, Right Angle
- Shell Size Connector Layout
- 1 DE E
- Orientation
- Right Angle
- Current Rating Amps
- 5A
- Contact Finish Thickness
- Flash
- Connector Type
- Receptacle, Female Sockets
- Flange Feature
- Mating Side, Female Screwlock (4-40)
- Insulation Resistance
- 1000000000Ohm
- Housing Material
- PBT
- Sıra Sayısı
- 2
- Plating
- Nickel
- Contact Type
- Signal
- RoHS Durumu
- RoHS Compliant
- Dielectric Material
- Polybutylene Terephthalate (PBT), Glass Filled
- Pitch
- 2.76mm
- Contact Materials
- Phosphor Bronze
- Özellikler
- Board Lock, Shielded
- Akım Değeri
- 3A
- Shell Material
- Steel
- Renk
- Black
- JESD-609 Kodu
- e4
- Yayın Yılı
- 2001
- Reliability
- COMMERCIAL
- Pcb Contact Pattern
- STAGGERED
- Dielectric Withstanding Voltage
- 1000VAC V
- Ambalaj
- Tray
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Connector Style
- D-Sub
- Seri
- XM3B
- Nominal Gerilim
- 300V
