XJ8D-1811

Teknik Özellikler

Pozisyon Sayısı

18

Depth

7.5mm

Sıra Sayısı

3

Insulation Materials

Polyphenylene Sulfide (PPS), Glass Filled

Contact Length Post

0.110 2.79mm

Terminal Adımı

2.54mm

Mil Conformance

NO

Housing Material

Polyphenylene

Kurşunsuz Kodu

yes

Uzunluk

15.2mm

Orientation

Straight

Contact Shape

Square

Nominal Gerilim

300V

Housing Color

Black

Montaj Tipi

Through Hole

Seri

XJ8

Material Flammability Rating

UL94 V-0

Max Voltage Rating Ac

300V

RoHS Durumu

RoHS Compliant

Iec Conformance

NO

Fabrika Tedarik Süresi

8 Weeks

Contact Type

Male Pin

Parça Durumu

Active

Contact Finish Mating

Gold

Contact Lengthmating

0.169 4.30mm

ECCN Kodu

EAR99

Overall Contact Length

0.339 8.60mm

Max Current Rating

2A

Fastening Type

Push-Pull

Terminal

Solder

JESD-609 Kodu

e4

Montaj

Through Hole

Contact Resistance

20mOhm

Pitch Mating

0.100 2.54mm

Contact Finish Thickness Mating

5.90μin 0.150μm

Ambalaj

Bulk

Din Conformance

NO

Çalışma Sıcaklığı

-55°C~105°C

Row Spacing Mating

0.100 (2.54mm)

Insulation Height

0.059 1.50mm
