Teknik Özellikler
- Contact Finish
- Gold
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Min. Çalışma Sıcaklığı
- -55°C
- RoHS Durumu
- RoHS Compliant
- Montaj Tipi
- Through Hole
- Length Termination
- 0.118 inch
- Maks. Çalışma Sıcaklığı
- 105°C
- Montaj
- Through Hole
- Özellikler
- Board Lock
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 8 Weeks
- Connector Type
- Plug, Center Strip Contacts
- Rated Current Signal
- 0.5A
- Number Of Conductors
- ONE
- Reliability
- COMMERCIAL
- Seri
- XH3
- Radyasyon Dayanımı
- No
- Insertion Forcemax
- .7784 N
- Orientation
- Straight
- Pozisyon Sayısı
- 20
- Height Above Board
- 0.500 12.70mm
- Total Number Of Contacts
- 20
- Dielectric Withstanding Voltage
- 650VAC V
- Yayın Yılı
- 1996
- Insulation Materials
- POLYBUTYLENE TEREPHTHALATE
- Pitch
- 0.050 1.27mm
- Withdrawl Forcemin
- .10008 N
- Durability
- 400 Cycles
- Reference Standard
- UL
- Contact Materials
- PHOSPHOR BRONZE
- Number Of Pcb Rows
- 4
- Insulation Resistance
- 1000000000Ohm
- Insulator Color
- GRAY
- Max Voltage Rating Ac
- 125V
- Contact Resistance
- 30mOhm
- Terminal
- Solder
- Pcb Contact Row Spacing
- 1.905 mm
- Ambalaj
- Bulk
- Contact Pattern
- RECTANGULAR
- Stack Height Mating
- 16mm 17mm 19mm 20mm
