Adet bazlı fiyat
- 1+ adet$1.52
- 10+ adet$1.44
- 100+ adet$1.36
- 500+ adet$1.28
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Radyasyon Dayanımı
- No
- Pozisyon Sayısı
- 30
- Number Of Conductors
- ONE
- Body Breadth
- 0.197 inch
- Contact Shape
- Square
- Insulation Height
- 0.098 2.50mm
- Style
- Board to Board or Cable
- Reference Standard
- UL
- ECCN Kodu
- EAR99
- Terminal
- Solder
- Number Of Pcb Rows
- 2
- Filter Feature
- NO
- Max Current Rating
- 3A
- Montaj Tipi
- Through Hole
- Material Flammability Rating
- UL94 V-0
- Length Termination
- 0.118 inch
- Pitch Mating
- 0.100 2.54mm
- Overall Contact Length
- 0.453 11.50mm
- Max Voltage Rating Ac
- 300V
- Contact Plating
- Gold, Tin
- RoHS Durumu
- RoHS Compliant
- Rated Current Signal
- 3A
- Parça Durumu
- Active
- Nominal Gerilim
- 300V
- Çalışma Sıcaklığı
- -55°C~105°C
- Shrouding
- Unshrouded
- Insulation Materials
- Polybutylene Terephthalate (PBT), Glass Filled
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Ambalaj
- Bulk
- Yayın Yılı
- 2001
- Plating Thickness
- 79μin
- Option
- GENERAL PURPOSE
- Row Spacing Mating
- 0.100 (2.54mm)
- Number Of Positions Loaded
- All
- Mixed Contacts
- NO
- Insulation Resistance
- 1000000000Ohm
- HTS Kodu
- 8536.69.40.40
- Connector Type
- Header
- Body Length Or Diameter
- 1.5 inch
- Orientation
- Straight
