Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Row Spacing
- 0.100 (2.54mm)
- Nominal Gerilim
- 300V
- Wire Gauge
- 24 AWG
- Parça Durumu
- Active
- Wirecable Gauge
- 24 AWG
- Yayın Yılı
- 2002
- Ambalaj
- Bulk
- Insulation Materials
- GLASS FILLED POLYBUTYLENE TEREPHTHALATE
- Pitch
- 0.100 2.54mm
- Insertion Forcemax
- 1.946 N
- Akım Değeri
- 3A
- Renk
- Black
- Cable Termination
- IDC
- Rated Current Signal
- 3A
- RoHS Durumu
- RoHS Compliant
- Operating Temperature Min
- -55°C
- Contact Finish Thickness
- 5.90μin 0.150μm
- Additional Feature
- POLARISED
- Montaj Tipi
- Free Hanging (In-Line)
- Pozisyon Sayısı
- 20
- Filter Feature
- NO
- Reference Standard
- UL
- Seri
- XG5
- Contact Design
- PREASSEM CONN
- Body Depth
- 0.567 inch
- Reliability
- COMMERCIAL
- Din Conformance
- NO
- Dielectric Withstanding Voltage
- 650VAC V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Materials
- Bronze
- Özellikler
- Closed End, Polarizing Key
- Wire Type
- Discrete
- Sıra Sayısı
- 2
- Contact Type
- Female Socket
- Operating Temperature Max
- 85°C
- Body Length Or Diameter
- 1.181 inch
- Ul Flammability Code
- 94V-0
- Connector Type
- Receptacle
- Insulation Resistance
- 1000000000Ohm
- Mil Conformance
- NO
