Adet bazlı fiyat
- 1+ adet$6.28
- 10+ adet$5.92
- 100+ adet$5.59
- 500+ adet$5.27
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Montaj Tipi
- Free Hanging (In-Line)
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Contact Finish Thickness
- 5.90μin 0.150μm
- Max Current Rating
- 1A
- Additional Feature
- STANDARD: MIL-C-83503
- Terminal
- IDT
- Filter Feature
- NO
- Body Breadth
- 0.37 inch
- Pozisyon Sayısı
- 60
- Yayın Yılı
- 2002
- Ambalaj
- Tray
- Row Spacing
- 0.100 (2.54mm)
- Polarization Key
- POLARIZED KEY
- Nominal Gerilim
- 250V
- Parça Durumu
- Active
- Wire Gauge
- 28 AWG
- Wirecable Gauge
- 28 AWG
- Maks. Çalışma Sıcaklığı
- 105°C
- Cable Termination
- IDC
- Housing Material
- Polybutylene
- Rated Current Signal
- 1A
- RoHS Durumu
- RoHS Compliant
- Max Voltage Rating Ac
- 250V
- Pitch
- 0.100 2.54mm
- Akım Değeri
- 1A
- Renk
- Black
- Mil Conformance
- YES
- Iec Conformance
- NO
- Fabrika Tedarik Süresi
- 17 Weeks
- Total Number Of Contacts
- 60
- Montaj
- Cable, Free Hanging
- Ul Flammability Code
- 94V-0
- Orientation
- Right Angle
- Uzunluk
- 80.8mm
- Connector Type
- Receptacle
- Insulation Resistance
- 1GOhm
- Mixed Contacts
- NO
- Min. Çalışma Sıcaklığı
- -55°C
- Option
- GENERAL PURPOSE
- Durability
- 50 Cycles
