Teknik Özellikler
- Mixed Contacts
- NO
- Min. Çalışma Sıcaklığı
- -55°C
- Contact Finish
- Gold
- Wirecable Type
- Ribbon
- Plating Thickness
- 6μin
- Option
- GENERAL PURPOSE
- Durability
- 50 Cycles
- Montaj
- Cable, Free Hanging
- Total Number Of Contacts
- 40
- Fabrika Tedarik Süresi
- 7 Weeks
- Iec Conformance
- NO
- Mil Conformance
- YES
- Insulation Resistance
- 1GOhm
- Orientation
- Right Angle
- Ul Flammability Code
- 94V-0
- Connector Type
- Receptacle
- Uzunluk
- 55.4mm
- Sıra Sayısı
- 2
- Wire Type
- Ribbon Cable
- Contact Type
- Female Socket
- Contact Resistance
- 20mOhm
- JESD-609 Kodu
- e3
- Contact Materials
- Bronze
- Özellikler
- Feed Through, Polarizing Key
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Din Conformance
- NO
- Dielectric Withstanding Voltage
- 500VAC V
- Reliability
- MIL-C-83503
- Seri
- XG4
- Contact Gender
- Female
- Filter Feature
- NO
- Terminal
- IDT
- ECCN Kodu
- EAR99
- Pozisyon Sayısı
- 40
- Radyasyon Dayanımı
- No
- Montaj Tipi
- Free Hanging (In-Line)
- Max Current Rating
- 3A
- Additional Feature
- STANDARD: MIL-C-83503
- Contact Finish Thickness
- 5.90μin 0.150μm
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
