Teknik Özellikler
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Contact Finish Thickness
- 5.90μin 0.150μm
- Additional Feature
- STANDARD: MIL-C-83503
- Max Current Rating
- 1A
- Montaj Tipi
- Free Hanging (In-Line)
- Body Breadth
- 0.37 inch
- Pozisyon Sayısı
- 20
- ECCN Kodu
- EAR99
- Terminal
- IDT
- Filter Feature
- NO
- Row Spacing
- 0.100 (2.54mm)
- Parça Durumu
- Active
- Wire Gauge
- 28 AWG
- Wirecable Gauge
- 28 AWG
- Maks. Çalışma Sıcaklığı
- 105°C
- Polarization Key
- POLARIZED KEY
- Nominal Gerilim
- 250V
- Yayın Yılı
- 2002
- Ambalaj
- Tray
- Pitch
- 0.100 2.54mm
- Renk
- Black
- Akım Değeri
- 1A
- Rated Current Signal
- 1A
- Housing Material
- Polybutylene
- Cable Termination
- IDC
- Max Voltage Rating Ac
- 250V
- RoHS Durumu
- RoHS Compliant
- HTS Kodu
- 8536.69.40.40
- Connector Type
- Receptacle
- Uzunluk
- 30mm
- Depth
- 9.5mm
- Orientation
- Right Angle
- Ul Flammability Code
- 94V-0
- Insulation Resistance
- 1GOhm
- REACH Uyumluluk Kodu
- unknown
- Mil Conformance
- YES
- Total Number Of Contacts
- 20
- Fabrika Tedarik Süresi
- 9 Weeks
- Iec Conformance
- NO
- Montaj
- Cable, Free Hanging
