Teknik Özellikler
- Pitch
- 0.100 2.54mm
- Renk
- Black
- Akım Değeri
- 1A
- Rated Current Signal
- 1A
- Housing Material
- Polybutylene
- Cable Termination
- IDC
- Max Voltage Rating Ac
- 250V
- RoHS Durumu
- RoHS Compliant
- Row Spacing
- 0.100 (2.54mm)
- Wirecable Gauge
- 28 AWG
- Maks. Çalışma Sıcaklığı
- 105°C
- Parça Durumu
- Active
- Wire Gauge
- 28 AWG
- Nominal Gerilim
- 250V
- Polarization Key
- POLARIZED KEY
- Yayın Yılı
- 2002
- Ambalaj
- Tray
- Body Breadth
- 0.37 inch
- Pozisyon Sayısı
- 16
- Filter Feature
- NO
- Terminal
- IDT
- Contact Finish Thickness
- 5.90μin 0.150μm
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Additional Feature
- STANDARD: MIL-C-83503
- Max Current Rating
- 1A
- Montaj Tipi
- Free Hanging (In-Line)
- Özellikler
- Feed Through, Polarizing Key, Strain Relief
- Contact Materials
- Bronze
- JESD-609 Kodu
- e3
- Contact Type
- Female Socket
- Contact Resistance
- 20mOhm
- Sıra Sayısı
- 2
- Wire Type
- Ribbon Cable
- Contact Gender
- Female
- Seri
- XG4
- Fastening Type
- Latch Lock/Eject Hooks
- Reliability
- MIL-C-83503
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Din Conformance
- NO
- Dielectric Withstanding Voltage
- 500VAC V
