Teknik Özellikler
- Contact Gender
- Female
- Seri
- XG4
- Reliability
- MIL-C-83503
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Dielectric Withstanding Voltage
- 500VAC V
- Din Conformance
- NO
- Contact Materials
- Bronze
- Özellikler
- Feed Through, Polarizing Key
- JESD-609 Kodu
- e3
- Sıra Sayısı
- 2
- Wire Type
- Ribbon Cable
- Contact Type
- Female Socket
- Contact Resistance
- 20mOhm
- Body Length Or Diameter
- 0.98 inch
- Orientation
- Right Angle
- Ul Flammability Code
- 94V-0
- Connector Type
- Receptacle
- Insulation Resistance
- 1GOhm
- Iec Conformance
- NO
- Fabrika Tedarik Süresi
- 8 Weeks
- Total Number Of Contacts
- 16
- Mil Conformance
- YES
- Montaj
- Cable, Free Hanging
- Durability
- 50 Cycles
- Option
- GENERAL PURPOSE
- Wirecable Type
- Ribbon
- Contact Finish
- Gold
- Plating Thickness
- 6μin
- Mixed Contacts
- NO
- Min. Çalışma Sıcaklığı
- -55°C
- Row Spacing
- 0.100 (2.54mm)
- Nominal Gerilim
- 250V
- Polarization Key
- POLARIZED KEY
- Maks. Çalışma Sıcaklığı
- 105°C
- Wirecable Gauge
- 28 AWG
- Wire Gauge
- 28 AWG
- Parça Durumu
- Active
- Yayın Yılı
- 2002
- Ambalaj
- Tray
- Pitch
- 0.100 2.54mm
