Adet bazlı fiyat
- 1+ adet$4.56
- 10+ adet$4.31
- 100+ adet$4.06
- 500+ adet$3.83
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Finish Mating
- Gold
- Contact Materials
- Brass, Nickel
- Contact Length Post
- 0.126 3.20mm
- Özellikler
- Keying Slot
- JESD-609 Kodu
- e3
- Sıra Sayısı
- 2
- Contact Type
- Male Pin
- RoHS Durumu
- RoHS Compliant
- Insulation Color
- Black
- Contact Finish Post
- Tin
- Shrouding
- Shrouded - 4 Wall
- Nominal Gerilim
- 300V
- Çalışma Sıcaklığı
- -55°C~105°C
- Seri
- XG4
- Parça Durumu
- Active
- Yayın Yılı
- 2002
- Fastening Type
- Push-Pull
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Insulation Materials
- Polybutylene Terephthalate (PBT), Glass Filled
- Insulation Height
- 0.323 8.20mm
- Contact Shape
- Square
- Pozisyon Sayısı
- 64
- Terminal
- Solder
- Number Of Positions Loaded
- All
- ECCN Kodu
- EAR99
- Row Spacing Mating
- 0.100 (2.54mm)
- Style
- Board to Board or Cable
- Contact Finish Thickness Mating
- 5.90μin 0.150μm
- Current Rating Amps
- 3A
- Connector Type
- Header
- HTS Kodu
- 8536.69.40.40
- REACH Uyumluluk Kodu
- unknown
- Pitch Mating
- 0.100 2.54mm
- Fabrika Tedarik Süresi
- 15 Weeks
- Contact Lengthmating
- 0.240 6.10mm
- Material Flammability Rating
- UL94 V-0
- Montaj Tipi
- Through Hole, Right Angle
