Adet bazlı fiyat
- 1+ adet$0.78
- 10+ adet$0.73
- 100+ adet$0.69
- 500+ adet$0.65
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Pitch Mating
- 0.100 2.54mm
- Fabrika Tedarik Süresi
- 7 Weeks
- Contact Lengthmating
- 0.240 6.10mm
- Material Flammability Rating
- UL94 V-0
- Montaj
- Through Hole
- Montaj Tipi
- Through Hole, Right Angle
- Orientation
- Right Angle
- HTS Kodu
- 8536.69.40.40
- Connector Type
- Header
- Uzunluk
- 70.8mm
- Depth
- 12.2mm
- Max Current Rating
- 3A
- REACH Uyumluluk Kodu
- unknown
- Terminal
- Solder
- ECCN Kodu
- EAR99
- Number Of Positions Loaded
- All
- Row Spacing Mating
- 0.100 (2.54mm)
- Contact Finish Thickness Mating
- 5.90μin 0.150μm
- Style
- Board to Board or Cable
- Insulation Height
- 0.323 8.20mm
- Contact Shape
- Square
- Pozisyon Sayısı
- 50
- Yayın Yılı
- 2002
- Fastening Type
- Push-Pull
- Housing Color
- Black
- Ambalaj
- Tray
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Insulation Materials
- Polybutylene Terephthalate (PBT), Glass Filled
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Contact Finish Post
- Tin
- Contact Gender
- Male
- Shrouding
- Shrouded - 4 Wall
- Seri
- XG4
- Çalışma Sıcaklığı
- -55°C~105°C
- Parça Durumu
- Active
- Sıra Sayısı
- 2
- Housing Material
- Polybutylene
- Contact Resistance
- 20mOhm
- Contact Type
- Male Pin
- RoHS Durumu
- RoHS Compliant
