Adet bazlı fiyat
- 1+ adet$0.70
- 10+ adet$0.66
- 100+ adet$0.62
- 500+ adet$0.58
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Gender
- Male
- Shrouding
- Shrouded - 4 Wall
- Contact Finish Post
- Tin
- Parça Durumu
- Active
- Seri
- XG4
- Çalışma Sıcaklığı
- -55°C~105°C
- Housing Color
- Black
- Fastening Type
- Push-Pull
- Yayın Yılı
- 2002
- Insulation Materials
- Polybutylene Terephthalate (PBT), Glass Filled
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Ambalaj
- Tray
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Özellikler
- Keying Slot
- Contact Length Post
- 0.126 3.20mm
- Contact Finish Mating
- Gold
- Contact Materials
- Brass, Nickel
- JESD-609 Kodu
- e3
- Akım Değeri
- 3A
- Overall Contact Length
- 0.480 12.19mm
- Contact Resistance
- 20mOhm
- Contact Type
- Male Pin
- Housing Material
- Polybutylene
- Sıra Sayısı
- 2
- Max Voltage Rating Ac
- 300V
- RoHS Durumu
- RoHS Compliant
- Connector Type
- Header
- Uzunluk
- 70.8mm
- Depth
- 8.5mm
- Orientation
- Straight
- Max Current Rating
- 3A
- REACH Uyumluluk Kodu
- unknown
- Fabrika Tedarik Süresi
- 8 Weeks
- Pitch Mating
- 0.100 2.54mm
- Montaj Tipi
- Through Hole
- Contact Lengthmating
- 0.240 6.10mm
- Material Flammability Rating
- UL94 V-0
- Montaj
- Through Hole
- Contact Shape
- Square
- Insulation Height
- 0.335 8.51mm
