Adet bazlı fiyat
- 1+ adet$4.66
- 10+ adet$4.40
- 100+ adet$4.15
- 500+ adet$3.91
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Connector Type
- Header
- Contact Lengthmating
- 0.240 6.10mm
- Shrouding
- Shrouded - 4 Wall
- Insulation Resistance
- 1GOhm
- Contact Finish Mating
- Gold
- Contact Type
- Male Pin
- Parça Durumu
- Active
- Akım Değeri
- 3A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yayın Yılı
- 2002
- Fabrika Tedarik Süresi
- 13 Weeks
- Contact Materials
- Brass, Nickel
- Contact Finish Post
- Tin
- Number Of Positions Loaded
- All
- Style
- Board to Cable/Wire
- Material Flammability Rating
- UL94 V-0
- RoHS Durumu
- RoHS Compliant
- Max Voltage Rating Ac
- 300V
- Montaj Tipi
- Through Hole, Right Angle
- Row Spacing Mating
- 0.100 (2.54mm)
- Seri
- XG4
- Insulation Height
- 0.335 8.51mm
- Çalışma Sıcaklığı
- -55°C~105°C
- Insulation Color
- Black
- Ambalaj
- Bulk
- Orientation
- Right Angle
- Contact Shape
- Square
- Montaj
- Through Hole
- Contact Resistance
- 20mOhm
- JESD-609 Kodu
- e3
- Pitch Mating
- 0.100 2.54mm
- Contact Finish Thickness Mating
- 5.90μin 0.150μm
- Housing Material
- PBT
- Terminal
- Solder
- Radyasyon Dayanımı
- No
- Fastening Type
- Latch Lock/Eject Hooks, Short
- Contact Length Post
- 0.126 3.20mm
- Özellikler
- Keying Slot, Mounting Flange
- Insulation Materials
- Polybutylene Terephthalate (PBT), Glass Filled
- Contact Gender
- Male
