Teknik Özellikler
- Contact Shape
- Square
- Orientation
- Right Angle
- Ambalaj
- Bulk
- Çalışma Sıcaklığı
- -55°C~105°C
- Insulation Color
- Black
- Housing Material
- PBT
- JESD-609 Kodu
- e3
- Contact Resistance
- 20mOhm
- Montaj
- Through Hole
- Pitch Mating
- 0.100 2.54mm
- Contact Finish Thickness Mating
- 5.90μin 0.150μm
- Radyasyon Dayanımı
- No
- Fastening Type
- Latch Lock/Eject Hooks, Short
- Contact Length Post
- 0.126 3.20mm
- Terminal
- Solder
- Pozisyon Sayısı
- 50
- Sıra Sayısı
- 2
- Max Current Rating
- 3A
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Contact Gender
- Male
- Insulation Materials
- Polybutylene Terephthalate (PBT), Glass Filled
- Özellikler
- Keying Slot, Mounting Flange
- Connector Type
- Header
- Contact Lengthmating
- 0.240 6.10mm
- Shrouding
- Shrouded - 4 Wall
- Contact Type
- Male Pin
- Parça Durumu
- Active
- Contact Finish Mating
- Gold
- Insulation Resistance
- 1GOhm
- Yayın Yılı
- 2002
- Fabrika Tedarik Süresi
- 15 Weeks
- Contact Materials
- Brass, Nickel
- Contact Finish Post
- Tin
- Number Of Positions Loaded
- All
- Akım Değeri
- 3A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- Through Hole, Right Angle
- Row Spacing Mating
- 0.100 (2.54mm)
- Seri
- XG4
- Insulation Height
- 0.335 8.51mm
