Adet bazlı fiyat
- 1+ adet$1.15
- 10+ adet$1.08
- 100+ adet$1.02
- 500+ adet$0.96
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Insulation Color
- Black
- Çalışma Sıcaklığı
- -55°C~105°C
- Contact Shape
- Square
- Orientation
- Right Angle
- Ambalaj
- Tray
- Contact Finish Thickness Mating
- 5.90μin 0.150μm
- Pitch Mating
- 0.100 2.54mm
- JESD-609 Kodu
- e3
- Contact Resistance
- 20mOhm
- Montaj
- Through Hole
- Housing Material
- PBT
- Terminal
- Solder
- Contact Length Post
- 0.126 3.20mm
- Fastening Type
- Latch Lock/Eject Hooks, Long
- Radyasyon Dayanımı
- No
- Özellikler
- Keying Slot, Mounting Flange
- Insulation Materials
- Polybutylene Terephthalate (PBT), Glass Filled
- Contact Gender
- Male
- Contact Finish Thickness Post
- 78.7μin 2.00μm
- Max Current Rating
- 3A
- Sıra Sayısı
- 2
- Pozisyon Sayısı
- 50
- Shrouding
- Shrouded - 4 Wall
- Contact Lengthmating
- 0.240 6.10mm
- Connector Type
- Header
- Contact Finish Mating
- Gold
- Parça Durumu
- Active
- Reach Svhc
- No SVHC
- Contact Type
- Male Pin
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Akım Değeri
- 3A
- Number Of Positions Loaded
- All
- Contact Finish Post
- Tin
- Contact Materials
- Brass, Nickel
- Fabrika Tedarik Süresi
- 9 Weeks
- Yayın Yılı
- 2002
- RoHS Durumu
- RoHS Compliant
- Max Voltage Rating Ac
- 300V
- Material Flammability Rating
- UL94 V-0
- Style
- Board to Cable/Wire
