Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Parça Durumu
- Active
- ECCN Kodu
- EAR99
- Montaj Tipi
- Through Hole
- Rated Current Signal
- 1A
- Seri
- XG2
- Max Voltage Rating Ac
- 250V
- RoHS Durumu
- RoHS Compliant
- Iec Conformance
- NO
- Fabrika Tedarik Süresi
- 9 Weeks
- Number Of Conductors
- ONE
- Total Number Of Contacts
- 10
- Housing Material
- PBT
- Wire Gauge
- 28 AWG
- Cable Pitch
- 0.050 1.27mm
- Pitch
- 2.54mm
- Body Length Or Diameter
- 0.705 inch
- Orientation
- Right Angle
- Flammability Rating
- UL94 V-0
- Reliability
- COMMERCIAL
- Nominal Gerilim
- 250V
- Contact Finish
- Tin
- Sıra Sayısı
- 2
- Pozisyon Sayısı
- 10
- Number Of Pcb Rows
- 2
- Contact Gender
- Female
- Cable Termination
- IDC
- Min. Çalışma Sıcaklığı
- -55°C
- Mil Conformance
- NO
- Boardside Pitch
- 0.100 2.54mm
- Contact Pattern
- RECTANGULAR
- Row Spacing
- 0.100 (2.54mm)
- HTS Kodu
- 8536.69.40.40
- Dielectric Withstanding Voltage
- 500VAC V
- Insulation Resistance
- 1GOhm
- Option
- GENERAL PURPOSE
- Connector Type
- Ribbon Cable, DIP Header
- Wirecable Gauge
- 28 AWG
- Ul Flammability Code
- 94V-0
- Reference Standard
- UL
- Filter Feature
- NO
