Teknik Özellikler
- Total Number Of Contacts
- 40
- Orientation
- Right Angle
- Akım Değeri
- 500mA
- Contact Finish
- Gold
- Cable End Type
- Tapered
- Actuatorcolor
- Brown
- Pcb Contact Pattern
- RECTANGULAR
- Contact Finish Thickness
- 5.90μin 0.150μm
- Material Flammability Rating
- UL94 V-0
- Contact Materials
- Copper Alloy
- Nominal Gerilim
- 50V
- Actuator Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Body Breadth
- 0.043 inch
- Reliability
- COMMERCIAL
- Fabrika Tedarik Süresi
- 11 Weeks
- Current Rating Amps
- 0.5A
- Flammability Rating
- UL94 V-0
- ECCN Kodu
- EAR99
- Pitch
- 0.020 0.50mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Locking Feature
- Rotary Lock, Backlock
- Montaj
- Surface Mount
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Sıra Sayısı
- 1
- Contact Resistance
- 60mOhm
- Body Length Or Diameter
- 0.866 inch
- Contact Pattern
- RECTANGULAR
- Reach Svhc
- Unknown
- Pozisyon Sayısı
- 40
- Gender
- Receptacle
- JESD-609 Kodu
- e4
- Housing Color
- Natural
- Çalışma Sıcaklığı
- -30°C~85°C
- Terminal
- Solder
- Yayın Yılı
- 2013
- Height Above Board
- 0.044 1.12mm
- Ffc Fcb Thickness
- 0.30mm
- Seri
- XF2W
- Contact Style
- BELLOWED TYPE
- Ambalaj
- Cut Tape (CT)
