Teknik Özellikler
- REACH Uyumluluk Kodu
- unknown
- Mating Cycles
- 20
- RoHS Durumu
- RoHS Compliant
- Contact Gender
- FEMALE
- Option
- GENERAL PURPOSE
- Seri
- XF2W
- Flat Flex Type
- FPC
- Height Above Board
- 0.044 1.12mm
- Çalışma Sıcaklığı
- -30°C~85°C
- JESD-609 Kodu
- e4
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Montaj
- Surface Mount
- Locking Feature
- Rotary Lock, Backlock
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Pitch
- 0.020 0.50mm
- Contact Resistance
- 60mOhm
- Contact Pattern
- RECTANGULAR
- Mixed Contacts
- NO
- Din Conformance
- NO
- Body Breadth
- 0.043 inch
- Material Flammability Rating
- UL94 V-0
- Pcb Contact Pattern
- RECTANGULAR
- Actuatorcolor
- Brown
- Actuator Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Reference Standard
- UL
- Filter Feature
- NO
- Plating Thickness
- 6μin
- Mil Conformance
- NO
- Ambalaj
- Cut Tape (CT)
- Contact Style
- BELLOWED TYPE
- Parça Durumu
- Obsolete
- Ffc Fcb Thickness
- 0.30mm
- Number Of Pcb Rows
- 1
- Montaj Tipi
- Surface Mount, Right Angle
- Terminal
- Solder
- Yayın Yılı
- 2006
- Housing Color
- Natural
- Pozisyon Sayısı
- 9
- Body Length Or Diameter
- 0.256 inch
- Iec Conformance
- NO
