Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- ECCN Kodu
- EAR99
- Flammability Rating
- UL94 V-0
- Fabrika Tedarik Süresi
- 11 Weeks
- Current Rating Amps
- 0.5A
- Reliability
- COMMERCIAL
- Sıra Sayısı
- 1
- Contact Finish
- Gold
- Cable End Type
- Tapered
- Akım Değeri
- 500mA
- Orientation
- Right Angle
- Total Number Of Contacts
- 4
- Nominal Gerilim
- 50V
- Contact Materials
- Copper Alloy
- Contact Finish Thickness
- 5.90μin 0.150μm
- Number Of Pcb Rows
- 1
- Montaj Tipi
- Surface Mount, Right Angle
- Plating Thickness
- 6μin
- Ambalaj
- Cut Tape (CT)
- Contact Style
- BELLOWED TYPE
- Parça Durumu
- Obsolete
- Ffc Fcb Thickness
- 0.30mm
- Reference Standard
- UL
- Housing Color
- Natural
- Pozisyon Sayısı
- 4
- Reach Svhc
- Unknown
- Insulation Resistance
- 100MOhm
- Yayın Yılı
- 2013
- Terminal
- Solder
- Contact Pattern
- RECTANGULAR
- Contact Resistance
- 60mOhm
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Montaj
- Surface Mount
- Locking Feature
- Rotary Lock, Backlock
- Pitch
- 0.020 0.50mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Actuator Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Material Flammability Rating
- UL94 V-0
- Actuatorcolor
- Brown
- Pcb Contact Pattern
- RECTANGULAR
- Flat Flex Type
- FPC
