Adet bazlı fiyat
- 1+ adet$1.20
- 10+ adet$1.13
- 100+ adet$1.07
- 500+ adet$1.01
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Ffc Fcb Thickness
- 0.20mm
- Parça Durumu
- Obsolete
- Ambalaj
- Tape & Reel (TR)
- Contact Style
- BELLOWED TYPE
- Mil Conformance
- NO
- Montaj Tipi
- Surface Mount, Right Angle
- Ul Flammability Code
- 94V-0
- Number Of Pcb Rows
- 1
- Reference Standard
- UL
- Filter Feature
- NO
- Reach Svhc
- Unknown
- Pozisyon Sayısı
- 20
- Housing Color
- Natural
- Terminal
- Solder
- Yayın Yılı
- 2006
- Reliability
- COMMERCIAL
- Fabrika Tedarik Süresi
- 11 Weeks
- Current Rating Amps
- 0.5A
- ECCN Kodu
- EAR99
- Flammability Rating
- UL94 V-0
- Kurşunsuz Kodu
- yes
- Lead Pitch
- 500μm
- Sıra Sayısı
- 1
- Iec Conformance
- NO
- Total Number Of Contacts
- 20
- Orientation
- Right Angle
- Contact Finish
- Gold
- Cable End Type
- Tapered
- Akım Değeri
- 500mA
- Contact Materials
- Copper Alloy
- Contact Finish Thickness
- 5.90μin 0.150μm
- Uzunluk
- 12mm
- Additional Feature
- LOW PROFILE
- Seri
- XF2U
- Option
- GENERAL PURPOSE
- Flat Flex Type
- FPC
- RoHS Durumu
- RoHS Compliant
- Voltage Rated Ac
- 50V
- Dielectric Withstanding Voltage
- 250VAC V
- Gender
- Receptacle
