Adet bazlı fiyat
- 1+ adet$0.29
- 10+ adet$0.27
- 100+ adet$0.26
- 500+ adet$0.24
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Max Voltage Rating Dc
- 5.05kV
- Material Flammability Rating
- UL94 V-0
- Pcb Contact Pattern
- RECTANGULAR
- Actuatorcolor
- Black
- Actuator Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Din Conformance
- NO
- Depth
- 6.2mm
- Montaj
- Surface Mount
- Max Current Rating
- 500mA
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Pitch
- 0.020 0.50mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Locking Feature
- Rotary Lock, Backlock
- Contact Resistance
- 50mOhm
- Contact Pattern
- RECTANGULAR
- Mixed Contacts
- NO
- Voltage Rated Ac
- 50V
- Çalışma Sıcaklığı
- -30°C~85°C
- Voltage Rated Dc
- 50V
- Gender
- Receptacle
- JESD-609 Kodu
- e4
- Max Voltage Rating Ac
- 50V
- Kurşunsuz
- Lead Free
- Yükseklik
- 3.1mm
- Radyasyon Dayanımı
- No
- Height Above Board
- 0.083 2.10mm
- Seri
- XF2M
- Option
- GENERAL PURPOSE
- Flat Flex Type
- FPC
- Mating Cycles
- 20
- RoHS Durumu
- RoHS Compliant
- Total Number Of Contacts
- 50
- Orientation
- Right Angle
- Cable End Type
- Tapered
- Contact Finish
- Gold
- Akım Değeri
- 500mA
- Contact Materials
- Copper Alloy
- Contact Finish Thickness
- 5.90μin 0.150μm
- Additional Feature
- LOW PROFILE
- Uzunluk
- 29.1mm
