Teknik Özellikler
- Actuatorcolor
- Black
- Pcb Contact Pattern
- RECTANGULAR
- Material Flammability Rating
- UL94 V-0
- Actuator Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Max Voltage Rating Dc
- 5.05kV
- Pitch
- 0.020 0.50mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Locking Feature
- Rotary Lock, Backlock
- Montaj
- Surface Mount
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Max Current Rating
- 500mA
- Mixed Contacts
- NO
- Contact Pattern
- RECTANGULAR
- Contact Resistance
- 50mOhm
- Depth
- 6.2mm
- Din Conformance
- NO
- Height Above Board
- 0.083 2.10mm
- Radyasyon Dayanımı
- No
- Kurşunsuz
- Lead Free
- Dielectric Withstanding Voltage
- 250VAC V
- Gender
- Receptacle
- Max Voltage Rating Ac
- 50V
- JESD-609 Kodu
- e4
- Çalışma Sıcaklığı
- -30°C~85°C
- Mating Cycles
- 20
- RoHS Durumu
- RoHS Compliant
- Seri
- XF2M
- Option
- GENERAL PURPOSE
- Flat Flex Type
- FPC
- Contact Finish Thickness
- 5.90μin 0.150μm
- Contact Materials
- Copper Alloy
- Uzunluk
- 20.6mm
- Additional Feature
- LOW PROFILE
- Total Number Of Contacts
- 33
- Orientation
- Right Angle
- Akım Değeri
- 500mA
- Cable End Type
- Tapered
- Contact Finish
- Gold
- Lead Pitch
- 500μm
- Sıra Sayısı
- 1
