Adet bazlı fiyat
- 1+ adet$0.38
- 10+ adet$0.36
- 100+ adet$0.34
- 500+ adet$0.32
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Contact Materials
- Copper Alloy
- Contact Finish Thickness
- 5.90μin 0.150μm
- Uzunluk
- 20.1mm
- Additional Feature
- LOW PROFILE
- Total Number Of Contacts
- 32
- Orientation
- Right Angle
- Contact Finish
- Gold
- Cable End Type
- Tapered
- Akım Değeri
- 500mA
- Iec Conformance
- NO
- Lead Pitch
- 500μm
- Sıra Sayısı
- 1
- Fabrika Tedarik Süresi
- 8 Weeks
- Current Rating Amps
- 0.5A
- Reliability
- COMMERCIAL
- Flammability Rating
- UL94 V-0
- Terminal
- Solder
- Insulation Resistance
- 100MOhm
- Yayın Yılı
- 2004
- Reach Svhc
- No SVHC
- Housing Color
- Natural
- Pozisyon Sayısı
- 32
- Reference Standard
- UL
- Filter Feature
- NO
- Mil Conformance
- NO
- Plating Thickness
- 6μin
- Ffc Fcb Thickness
- 0.30mm
- Parça Durumu
- Active
- Ambalaj
- Tape & Reel (TR)
- Contact Style
- BELLOWED TYPE
- Number Of Pcb Rows
- 1
- Montaj Tipi
- Surface Mount, Right Angle
- Ul Flammability Code
- 94V-0
- Material Flammability Rating
- UL94 V-0
- Pcb Contact Pattern
- RECTANGULAR
- Actuatorcolor
- Black
- Actuator Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Max Voltage Rating Dc
- 5.05kV
- Montaj
- Surface Mount
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
