Teknik Özellikler
- Çalışma Sıcaklığı
- -30°C~85°C
- JESD-609 Kodu
- e4
- Max Voltage Rating Ac
- 50V
- Voltage Rated Dc
- 50V
- Gender
- Receptacle
- Dielectric Withstanding Voltage
- 250VAC V
- Kurşunsuz
- Lead Free
- Radyasyon Dayanımı
- No
- Height Above Board
- 0.047 1.20mm
- Contact Location
- Top
- Flat Flex Type
- FPC
- Option
- GENERAL PURPOSE
- Seri
- XF2L
- RoHS Durumu
- RoHS Compliant
- Mating Cycles
- 20
- Max Voltage Rating Dc
- 5.05kV
- Actuator Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Material Flammability Rating
- UL94 V-0
- Actuatorcolor
- Black
- Pcb Contact Pattern
- RECTANGULAR
- Din Conformance
- NO
- Depth
- 3.45mm
- Contact Resistance
- 30mOhm
- Contact Pattern
- RECTANGULAR
- Mixed Contacts
- NO
- Max Current Rating
- 500mA
- Housing Material
- Liquid Crystal Polymer (LCP), Halogen Free
- Montaj
- Surface Mount
- Locking Feature
- Slide Lock
- Nem Hassasiyeti (MSL)
- Not Applicable
- Pitch
- 0.020 0.50mm
- Housing Color
- Natural
- Pozisyon Sayısı
- 4
- Reach Svhc
- No SVHC
- Insulation Resistance
- 100MOhm
- Yayın Yılı
- 2004
- Terminal
- Solder
- Number Of Pcb Rows
- 1
- Özellikler
- Zero Insertion Force (ZIF)
- Montaj Tipi
- Surface Mount, Right Angle
