Teknik Özellikler
- Seri
- VX
- Max Voltage Rating Dc
- 250V
- Throw Configuration
- SPST
- Terminal
- Solder
- Orientation
- Straight
- Akım Değeri
- 5A
- Voltage Rated Dc
- 30V
- Weight
- 6.2g
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -25°C~80°C
- Yayın Yılı
- 2004
- REACH Uyumluluk Kodu
- unknown
- Montaj Tipi
- Chassis Mount
- Ingress Protection
- IP40
- Ambalaj
- Bulk
- ECCN Kodu
- EAR99
- Electricallife
- 500,000 Cycles
- Fabrika Tedarik Süresi
- 8 Weeks
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Current Rating Amps
- 5A AC/DC
- Operating Force
- 50gf
- Voltage Rated Ac
- 125V
- RoHS Durumu
- RoHS Compliant
- Switch Function
- Off-Mom
- Differential Travel
- 0.012 (0.3mm)
- Montaj
- Chassis Mount, Screw, Solder
- Contact Materials
- Silver
- Operating Position
- 0.579 (14.7mm)
- Terminal Stili
- Solder, Quick Connect - 0.187 (4.7mm)
- Release Force
- 5.099gf
- Actuator Type
- Round (Pin Plunger)
- Mechanical Life
- 50,000,000 Cycles
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Voltage Rating Ac
- 250V
- Overtravel
- 0.040 (1.0mm)
- Circuit
- SPST-NO
- Pretravel
- 0.047 (1.2mm)
