Adet bazlı fiyat
- 1+ adet$3.82
- 10+ adet$3.61
- 100+ adet$3.40
- 500+ adet$3.21
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Release Force
- 4.079gf
- Actuator Type
- Lever, Roller
- Operating Position
- 0.815 (20.7mm)
- HTS Kodu
- 8536.50.70.00
- Circuit
- SPDT
- Pretravel
- 0.063 (1.6mm)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- RoHS Compliant
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Reach Svhc
- Unknown
- Voltage Rated Ac
- 125V
- Operating Force
- 60gf
- Pretravelmax
- 1.6 mm
- Body Height
- 15.9mm
- Switch Function
- On-Mom
- Differential Travel
- 0.020 (0.5mm)
- Montaj Tipi
- Chassis Mount
- ECCN Kodu
- EAR99
- Contact Current Rating
- 100mA
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 10 Weeks
- Contact Currentacmax
- 0.1A
- Radyasyon Dayanımı
- No
- Max Voltage Rating Dc
- 30V
- Contact Currentdcmax
- 0.1A
- Voltage Rated Dc
- 30V
- Orientation
- Straight
- Akım Değeri
- 100mA
- Contact Dc Max Rating R Load
- .1A@30VDC
- Terminal Stili
- Solder, Quick Connect - 0.187 (4.7mm)
- Body Length Or Diameter
- 27.8mm
- Body Breadth
- 10.3 mm
- Mechanical Life
- 10,000,000 Cycles
- Overtravel
- 0.030 (0.76mm)
- Max Voltage Rating Ac
- 125V
- Current Rating Amps
- 100mA AC/DC
- Kurşunsuz
- Lead Free
- Montaj
- Chassis Mount, Panel, Screw, Solder
- Contact Materials
- Gold
- Ingress Protection
- IP40
