Adet bazlı fiyat
- 1+ adet$2.82
- 10+ adet$2.66
- 100+ adet$2.51
- 500+ adet$2.37
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Ambalaj
- Bulk
- Weight
- 6.2g
- Release Force
- 50gf
- Current Rating Amps
- 16A AC 600mA DC
- Actuator Travel
- 2.2 mm
- Switch Function
- On-Mom
- Operating Position
- 0.579 (14.7mm)
- Max Voltage Rating Dc
- 250V
- Operating Force
- 200gf
- Çalışma Sıcaklığı
- -25°C~80°C
- Parça Durumu
- Active
- Pretravel
- 0.047 (1.2mm)
- Depth
- 10.3mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Max Current Rating
- 16A
- Pretravelmax
- 1.2 mm
- RoHS Durumu
- RoHS Compliant
- Seri
- V
- Max Voltage Rating Ac
- 250V
- Mechanical Life
- 50,000,000 Cycles
- Circuit
- SPDT
- Body Height
- 15.9mm
- Terminal
- Solder
- Contact Current Rating
- 16A
- Montaj
- Chassis Mount, Screw, Solder
- Voltage Rated Ac
- 250V
- Fabrika Tedarik Süresi
- 15 Weeks
- Electricallife
- 100,000 Cycles
- Yayın Yılı
- 2002
- Ingress Protection
- IP40
- Contact Materials
- Silver
- ECCN Kodu
- EAR99
- Orientation
- Straight
- HTS Kodu
- 8536.50.90.40
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Akım Değeri
- 10A
- Terminal Stili
- Solder, Quick Connect - 0.187 (4.7mm)
- Voltage Rated Dc
- 30V
- REACH Uyumluluk Kodu
- unknown
- Differential Travel
- 0.016 (0.4mm)
