Teknik Özellikler
- Differential Travel
- 0.060 (1.5mm)
- Operating Force
- 60gf
- Actuator Type
- Lever, Simulated Roller
- Max Voltage Rating Ac
- 250V
- Orientation
- Straight
- Seri
- V
- Terminal Stili
- Solder, Quick Connect - 0.187 (4.7mm)
- Voltage Rated Dc
- 30V
- HTS Kodu
- 8536.50.70.00
- Release Force
- 6.118gf
- Pretravel
- 0.157 (4.0mm)
- Ambalaj
- Bulk
- Kurşunsuz
- Lead Free
- Montaj
- Chassis Mount, Screw, Solder
- Overtravel
- 0.062 (1.6mm)
- Montaj Tipi
- Chassis Mount
- Akım Değeri
- 6A
- Pretravelmax
- 3.3 mm
- Max Voltage Rating Dc
- 250V
- Contact Currentdcmax
- 10A
- Current Rating Amps
- 10A AC 100mA DC
- Actuator Travel
- 5.6 mm
- REACH Uyumluluk Kodu
- unknown
- Terminal
- Quick Connect
- Voltage Rated Ac
- 250V
- Body Length Or Diameter
- 27.8mm
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Obsolete
- Yayın Yılı
- 2004
- Nem Hassasiyeti (MSL)
- Not Applicable
- Mechanical Life
- 50,000,000 Cycles
- Switch Function
- On-Mom
- Çalışma Sıcaklığı
- -25°C~80°C
- Contact Materials
- Silver
- Body Breadth
- 10.3 mm
- Operating Position
- 0.738 (18.7mm)
- Electricallife
- 300,000 Cycles
- Body Height
- 15.9mm
- Circuit
- SPDT
- Switch Type
- SNAP ACTING/LIMIT SWITCH
