Teknik Özellikler
- Actuator Travel
- 2.5 mm
- Flammability Rating
- UL94 V-0
- Reach Svhc
- Unknown
- Terminal
- Quick Connect
- Voltage Rated Ac
- 250V
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Switch Function
- On-Mom
- Çalışma Sıcaklığı
- -25°C~80°C
- Contact Materials
- Silver
- Uzunluk
- 37.8mm
- Yayın Yılı
- 2002
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Mechanical Life
- 50,000,000 Cycles
- Operating Position
- 0.579 (14.7mm)
- Number Of Poles
- 1
- Electricallife
- 300,000 Cycles
- Weight
- 6.2g
- RoHS Durumu
- RoHS Compliant
- Circuit
- SPDT
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- ECCN Kodu
- EAR99
- Ingress Protection
- IP40
- Fabrika Tedarik Süresi
- 17 Weeks
- Operating Force
- 200gf
- Differential Travel
- 0.016 (0.4mm)
- Max Voltage Rating Ac
- 250V
- Actuator Type
- Round (Pin Plunger)
- Depth
- 10.3mm
- Orientation
- Straight
- Max Current Rating
- 10A
- Seri
- V
- Terminal Stili
- Quick Connect - 0.187 (4.7mm)
- HTS Kodu
- 8536.50.70.00
- Voltage Rated Dc
- 30V
- Pretravel
- 0.047 (1.2mm)
- Release Force
- 50gf
- Ambalaj
- Bulk
- Contact Current Rating
- 10A
- Kurşunsuz
- Lead Free
