Teknik Özellikler
- Actuator Material
- Stainless Steel
- Current Rating Amps
- 100mA AC/DC
- Kılıf / Paket
- 100
- Akım Değeri
- 100mA
- Contact Current Rating
- 100mA
- Terminal Stili
- Solder Lug
- Seri
- SSG
- Voltage Rated Dc
- 30V
- Operating Force
- 61gf
- Differential Travel
- 0.031 (0.8mm)
- Depth
- 6.4mm
- Orientation
- Straight
- Max Voltage Rating Ac
- 250V
- Sealing
- IP00
- Contact Currentacmax
- 0.1A
- Contact Materials
- Gold
- Çalışma Sıcaklığı
- -25°C~125°C
- Uzunluk
- 19.95mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Operating Position
- 0.345 (8.8mm)
- Voltage Rated Ac
- 125V
- Parça Durumu
- Active
- Reach Svhc
- Unknown
- Max Voltage Rating Dc
- 250V
- Contact Currentdcmax
- 0.1A
- Montaj
- Chassis Mount, Panel, Screw, Solder
- Montaj Tipi
- Chassis Mount
- Overtravel
- 0.040 (1.0mm)
- Kurşunsuz
- Lead Free
- Ambalaj
- Bulk
- Pretravelmax
- 1 mm
- Max Current Rating
- 100mA
- Release Force
- 6.118gf
- HTS Kodu
- 8536.50.70.00
- Actuator Type
- Lever, Straight
- RoHS Durumu
- RoHS Compliant
- ECCN Kodu
- EAR99
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Circuit
- SPDT
- Body Height
- 9.9mm
