Teknik Özellikler
- Operating Position
- 0.420 (10.7mm)
- Ingress Protection
- IP40
- Montaj Tipi
- Chassis Mount
- Orientation
- Straight
- Contact Currentdcmax
- 5A
- Parça Durumu
- Active
- Current Rating Amps
- 5A AC
- Differential Travel
- 0.031 (0.8mm)
- Max Voltage Rating Dc
- 14V
- Release Force
- 2.039gf
- Contact Currentacmax
- 5A
- Electricallife
- 200,000 Cycles
- Çalışma Sıcaklığı
- -25°C~85°C
- Montaj
- Chassis Mount, Panel, Screw
- Operating Force
- 16gf
- Overtravel
- 0.047 (1.2mm)
- Max Voltage Rating Ac
- 125V
- Voltage Rated Ac
- 125V
- Voltage Rated Dc
- 30V
- Terminal Stili
- Quick Connect - 0.110 (2.8mm)
- HTS Kodu
- 8536.50.70.00
- Nem Hassasiyeti (MSL)
- Not Applicable
- Kılıf / Paket
- 125
- Circuit
- SPDT
- Fabrika Tedarik Süresi
- 15 Weeks
- Pretravelmax
- 1.2 mm
- Body Breadth
- 6.4 mm
- Seri
- SS
- Contact Materials
- Silver
- Akım Değeri
- 4A
- Switch Function
- On-Mom
- Kurşunsuz Kodu
- yes
- Ambalaj
- Bulk
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Contact Current Rating
- 5A
- Reach Svhc
- Unknown
- Mechanical Life
- 30,000,000 Cycles
- Terminal
- Quick Connect
- Actuator Type
- Lever, Simulated Roller
- ECCN Kodu
- EAR99
