Teknik Özellikler
- Orientation
- Straight
- Contact Currentdcmax
- 5A
- Depth
- 6.4mm
- Montaj Tipi
- Through Hole
- Ingress Protection
- IP40
- Max Current Rating
- 5A
- Operating Position
- 0.420 (10.7mm)
- Differential Travel
- 0.031 (0.8mm)
- Current Rating Amps
- 5A AC
- Parça Durumu
- Active
- Voltage Rated Ac
- 125V
- Max Voltage Rating Ac
- 125V
- Overtravel
- 0.047 (1.2mm)
- Montaj
- Screw, Through Hole
- Operating Force
- 50gf
- Çalışma Sıcaklığı
- -25°C~85°C
- Electricallife
- 200,000 Cycles
- Contact Currentacmax
- 5A
- Release Force
- 6.118gf
- Max Voltage Rating Dc
- 14V
- Throw Configuration
- SPDT, SPST
- HTS Kodu
- 8536.50.70.00
- Terminal Stili
- PC Pin
- Voltage Rated Dc
- 30V
- Circuit
- SPDT
- Fabrika Tedarik Süresi
- 15 Weeks
- Uzunluk
- 22.2mm
- Nem Hassasiyeti (MSL)
- Not Applicable
- Contact Current Rating
- 5A
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Ambalaj
- Tray
- Switch Function
- On-Mom
- Kurşunsuz Kodu
- yes
- Akım Değeri
- 5A
- Contact Materials
- Silver
- Seri
- SS
- Terminal
- PC Pins
- Actuator Material
- Stainless Steel
- Mechanical Life
- 30,000,000 Cycles
- Reach Svhc
- Unknown
