Teknik Özellikler
- Pretravel
- 0.024 (0.6mm)
- Seri
- SS-P
- ECCN Kodu
- EAR99
- Circuit
- SPDT
- Ambalaj
- Tray
- Number Of Poles
- 1
- Uzunluk
- 19.8mm
- Pretravelmax
- 0.6 mm
- Voltage Rated Ac
- 125V
- Contact Currentacmax
- 3A
- Depth
- 6.4mm
- Montaj Tipi
- Chassis Mount
- Electricallife
- 100,000 Cycles
- RoHS Durumu
- RoHS Compliant
- Contact Current Rating
- 3A
- Actuator Type
- Round (Pin Plunger)
- Operating Position
- 0.330 (8.4mm)
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Kurşunsuz Kodu
- yes
- Montaj
- Chassis Mount, Screw
- Contact Currentdcmax
- 3A
- Weight
- 1.6g
- Yayın Yılı
- 2004
- Nem Hassasiyeti (MSL)
- Not Applicable
- Overtravel
- 0.015 (0.4mm)
- Terminal Stili
- Quick Connect - 0.110 (2.8mm)
- Mechanical Life
- 1,000,000 Cycles
- Max Current Rating
- 3A
- Contact Dc Max Rating R Load
- 3A@30VDC
- Contact Materials
- Silver
- Akım Değeri
- 3A
- Switch Function
- On-Mom
- Operating Force
- 153gf
- Release Force
- 20gf
- Terminal
- Quick Connect
- HTS Kodu
- 8536.50.70.00
- Max Voltage Rating Dc
- 30V
- Voltage Rated Dc
- 30V
- Current Rating Amps
- 3A AC/DC
- Parça Durumu
- Active
