Adet bazlı fiyat
- 1+ adet$0.82
- 10+ adet$0.78
- 100+ adet$0.73
- 500+ adet$0.69
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Circuit
- SPDT
- Ambalaj
- Tray
- Number Of Poles
- 1
- Uzunluk
- 19.8mm
- Voltage Rated Ac
- 125V
- Seri
- SS-P
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Contact Current Rating
- 3A
- Contact Currentacmax
- 3A
- Depth
- 6.4mm
- Montaj Tipi
- Chassis Mount
- Electricallife
- 100,000 Cycles
- Kurşunsuz Kodu
- yes
- Actuator Type
- Lever, Straight
- Operating Position
- 0.345 (8.8mm)
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Yayın Yılı
- 2004
- Nem Hassasiyeti (MSL)
- Not Applicable
- Montaj
- Chassis Mount, Screw
- Contact Currentdcmax
- 3A
- Akım Değeri
- 3A
- Contact Materials
- Silver
- Switch Function
- On-Mom
- Overtravel
- 0.040 (1.0mm)
- Terminal Stili
- Quick Connect - 0.110 (2.8mm)
- Mechanical Life
- 1,000,000 Cycles
- Max Current Rating
- 3A
- Contact Dc Max Rating R Load
- 3A@30VDC
- Max Voltage Rating Dc
- 30V
- Operating Force
- 51gf
- Release Force
- 5.099gf
- Terminal
- Quick Connect
- HTS Kodu
- 8536.50.70.00
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 11 Weeks
- REACH Uyumluluk Kodu
- unknown
- Ingress Protection
- IP40
- Voltage Rated Dc
- 30V
- Current Rating Amps
- 3A AC/DC
