Teknik Özellikler
- Akım Değeri
- 3A
- Contact Materials
- Silver
- Switch Function
- On-Mom
- Overtravel
- 0.039 (1.0mm)
- Terminal Stili
- Quick Connect - 0.110 (2.8mm)
- Mechanical Life
- 1,000,000 Cycles
- Max Current Rating
- 3A
- Contact Dc Max Rating R Load
- 3A@30VDC
- Max Voltage Rating Dc
- 30V
- Operating Force
- 51gf
- Release Force
- 5.099gf
- Terminal
- Quick Connect
- HTS Kodu
- 8536.50.70.00
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 19 Weeks
- Ingress Protection
- IP40
- Voltage Rated Dc
- 30V
- Current Rating Amps
- 3A AC/DC
- Differential Travel
- 0.031 (0.8mm)
- Reach Svhc
- Unknown
- Orientation
- Straight
- Çalışma Sıcaklığı
- -25°C~85°C
- Actuator Material
- Stainless Steel
- Max Voltage Rating Ac
- 125V
- Kurşunsuz
- Lead Free
- Circuit
- SPDT
- Ambalaj
- Tray
- Number Of Poles
- 1
- Uzunluk
- 22.15mm
- Voltage Rated Ac
- 125V
- Seri
- SS-P
- ECCN Kodu
- EAR99
- RoHS Durumu
- RoHS Compliant
- Contact Current Rating
- 3A
- Contact Currentacmax
- 3A
- Depth
- 6.4mm
- Montaj Tipi
- Chassis Mount
- Electricallife
- 100,000 Cycles
- Kurşunsuz Kodu
- yes
- Actuator Type
- Lever, Simulated Roller
