Adet bazlı fiyat
- 1+ adet$2.52
- 10+ adet$2.37
- 100+ adet$2.24
- 500+ adet$2.11
Sevkiyat
Stoktan aynı gün hazırlık
Orijinal ürün
Doğrulanmış tedarik
RoHS
Compliant
Destek
Teknik ekip desteği
Teknik Özellikler
- Max Voltage Rating Dc
- 30V
- Kurşunsuz
- Lead Free
- Circuit
- SPDT
- Contact Currentacmax
- 0.1A
- Differential Travel
- 0.031 (0.8mm)
- Voltage Rated Ac
- 125V
- Max Voltage Rating Ac
- 125V
- Yayın Yılı
- 2003
- Actuator Type
- Lever, Simulated Roller
- Parça Durumu
- Active
- Contact Dc Max Rating R Load
- .1A@30VDC
- Contact Materials
- Gold
- Ambalaj
- Bulk
- Contact Current Rating
- 100mA
- Nem Hassasiyeti (MSL)
- Not Applicable
- Fabrika Tedarik Süresi
- 15 Weeks
- Current Rating Amps
- 100mA AC/DC
- HTS Kodu
- 8536.50.70.00
- Body Length Or Diameter
- 19.8mm
- Montaj
- Panel, Through Hole
- Seri
- SS
- Operating Position
- 0.420 (10.7mm)
- Contact Currentdcmax
- 0.1A
- Voltage Rated Dc
- 30V
- Operating Force
- 16gf
- Kurşunsuz Kodu
- yes
- RoHS Durumu
- RoHS Compliant
- Body Breadth
- 6.4 mm
- Electricallife
- 200,000 Cycles
- Reach Svhc
- Unknown
- Montaj Tipi
- Through Hole
- Switch Function
- On-Mom
- Body Height
- 10.2mm
- Contact Ac Max Rating R Load
- .1A@125VAC
- Terminal Stili
- PC Pin
- Actuator Travel
- 2 mm
- Terminal
- PC Pin
- ECCN Kodu
- EAR99
- Overtravel
- 0.047 (1.2mm)
- Orientation
- Straight
